| 品牌： | 芯諾 |
| 型號： | XN-18V10W-M |
| 組件類型： | 單晶硅組件 |
| 轉換效率： | 18.4 % |
| 輸出功率： | 10 W |
| 電池片數量： | 36 片 |
| 外形尺寸： | 340*250*17 mm |
| 重量： | 0.9 kg |
| 封裝形式： | 紙箱包裝 |
| 工作電壓： | 18 V |
| 工作電流： | 0.55 A |
| 開路電壓： | 21.5 V |
| 開路電流： | 0.6 A |
| 產品認證： | CE |
| 可以定制： | 是 |
| XN-18V10W-M | |||||
| Maximum power (Wp) ***大功率 | 10w | ||||
| Maximum power voltage (V) 工作電壓 | 18v | ||||
| Maximum power current (A) 工作電流 | 0.55A | ||||
| Open circuit voltage (V) 開路電壓 | 21.5v | ||||
| Short circuit current (A) 短路電流 | 0.61A | ||||
| Number of cells (Pcs) 電池片數量 | 36 | ||||
| Size of module (mm) 電池板尺寸 | 340*250*17mm | ||||
| Maximum system voltage (V) | 1000 | ||||
| Temperature Range 工作溫度范圍 | -40℃ ---80℃ | ||||
| Tolerance Wattage (e.g. +/-5%) | ± 5% | ||||
| Surface Maximum Load Capacity | 60m/s (200kg/sq.m) | ||||
| Weight per piece (kg) 電池板重量 | ≈0.9kg | ||||
| Junction Box Type 接線盒 | PPO, black | ||||
| Cell Size(mm)硅片規格 | 156*156 | ||||
| Cell Efficiency (%) 轉換效率 | ≥18.4% | ||||
| frame (Material, Corners, etc.) 框架材料 | Anodized Aluminum Alloy鋁合金 | ||||
| Standard Test Conditions測試標準參數 | AM1.5 100MW/c㎡ 25℃ | ||||
| Warranty 產品保證 | 5 years for the whole product, for the power, 90% within the first decade, 80% for the next decade. | ||||
| FF (%) 電池板填充率 | ≥73.3% | ||||
